Project record

Tarifa fishing-wharf electrical utility upgrade

Official Tarifa fishing-wharf medium-voltage layout showing the existing 20 kV network and route to the new transformation centre

Gabitel execution project for APBA, drawing 02; exact-location design layout, not construction-progress or energisation evidence

The Algeciras Bay Port Authority awarded VES Renewable the Tarifa fishing-wharf utility electrification works, covering a 20 kV connection, 400 kVA transformer, medium- and low-voltage distribution, civil ducts and six user-supply interfaces.

Project signal

Award in Spain

Current status APBA awarded the EUR 273,030 works to VES Renewable; contract formalization and setting-out remain unpublished Source confidence Confirmed

Location

Spain / Europe

Segment

Fishing-wharf electrical distribution and utility connection

Status

APBA awarded the EUR 273,030 works to VES Renewable; contract formalization and setting-out remain unpublished / Confirmed

Last checked

9 August 2026

Coverage

Related sectors

Fishing-wharf electrical distribution and utility connection is the primary work classification. Related sectors connect this record to adjacent marine delivery and market coverage.

Subject index

Related subjects

These subject pages bring together related projects, technical articles, reports, and evidence methods.

Project anatomy

Contract scope and delivery roles

Client / authority
Presidency of the Algeciras Bay Port Authority (APBA)
Delivery parties
VES RENEWABLE, S.A. - awarded works contractor, Gabitel Soluciones Tecnicas, S.L. - execution-project designer, E-Distribucion Redes Digitales, S.L.U. - distribution-network access, equipment-approval and handover interface, Civil trenching, transformer, switchgear, cable, testing and other lower-tier suppliers or subcontractors - not identified in the cited public records
Contract route
PLACSP expediente 2026-037 records an ordinary simplified open works procedure, four tenders and award on 6 August 2026 to VES RENEWABLE, S.A. The award was published on 7 August at EUR 273,030.32 excluding VAT and EUR 330,366.68 including VAT, against a EUR 274,402.34 excluding-VAT tender baseline. The award notice requires formalization within a maximum of 15 business days after award notification; it is not itself a signed contract or notice to proceed.
Execution window
The controlling contract schedule is four months, with the PCAP starting the clock on the day after the setting-out verification act. No signed contract, setting-out act, licence confirmation, work programme, site possession, start certificate, energisation or reception record is public as of 9 August 2026.
Works package
Gabitel's execution project provides a 357.07 kW grid-access basis and a new 20 kV utility connection for fishing-wharf concession users. The design includes one prefabricated CTA4B or equivalent transformation centre; one 400 kVA, 20/0.42 kV oil-filled transformer; two motorised 24 kV, 630 A line cells; one 24 kV protection cell; one 1,600 A low-voltage board with four outgoing ways; a measured 190 m of 3x240+1x150 square-millimetre aluminium medium-voltage cable; 96.5 m of medium-voltage duct route; 66 m of 3x240/150 square-millimetre aluminium low-voltage circuit; six 400 A sectionalising boxes; six 250 A general protection boxes; six prefabricated enclosures; associated trenches, chambers, earthing, foundations, reinstatement and building feeders.
Marine interfaces
The works sit inside an operating fishing-wharf precinct and route electrical infrastructure beside harbour buildings and small-craft berths. The designed network serves concession buildings 1, 2, 3, 4, 6 and 7, plus the fuel dispenser and tide gauge, so access, buried-service surveys, trench safety, port traffic, continuous user supply and E-Distribucion acceptance are live interfaces. The package does not specify vessel plugs, berth cable-management systems, frequency conversion, ship connection, OPS controls or vessel commissioning.
Commercial evidence boundary
EUR 273,030.32 is the excluding-VAT award value and EUR 330,366.68 the including-VAT award total; neither is certified spend or a final account. The tender baseline was EUR 274,402.34 excluding VAT, producing a narrow price reduction. VES Renewable is the awardee, Gabitel the designer and E-Distribucion the network interface. Subcontracting is permitted and tenderers were asked to describe intended subcontracted units, but the public award record names no subcontractor, equipment manufacturer, testing specialist or package allocation.

Contract and delivery chain

Named roles and open packages

Named appointments are shown against the workstream they cover. Unallocated packages remain open until a project source identifies the responsible party.

Owner

Expediente 2026-037 fishing-wharf utility electrification

Named party
Algeciras Bay Port Authority
Status
Confirmed
Source position
The PLACSP record identifies APBA as contracting authority and defines the works location and procurement route. Source
Technical design

20 kV connection, transformation centre, LV distribution and civil works

Named party
Gabitel Soluciones Tecnicas, S.L.
Status
Confirmed
Source position
The approved execution project identifies Gabitel as author and fixes the electrical and civil design baseline. Source
Grid interface

357.07 kW access, 20 kV network connection and utility handover

Named party
E-Distribucion Redes Digitales, S.L.U.
Status
Confirmed
Source position
The execution project includes E-Distribucion's access-and-connection conditions and requires the MV, transformer and LV assets to meet utility standards for transfer. Source
Works award

Electrical installation and associated civil works

Named party
VES RENEWABLE, S.A.
Status
Confirmed
Source position
The 7 August award notice records VES Renewable at EUR 273,030.32 excluding VAT after four tenders. Source
MV and transformation

400 kVA transformer, two line cells, one protection cell, MV cable and earthing

Named party
VES Renewable and undisclosed suppliers or lower tiers
Status
Confirmed
Source position
The technical project fixes the design quantities; manufacturer, supply contract, installation progress and accepted test records remain unpublished. Source
LV user distribution

Four-way LV board, two distribution circuits, six sectionalising boxes and six protection boxes

Named party
VES Renewable and undisclosed suppliers or lower tiers
Status
Confirmed
Source position
The execution project defines the distribution topology and quantities, but no downstream appointment, as-built route, energisation or user handover is published. Source
Supply chain

Civil, transformer, switchgear, cable, testing and commissioning lower tiers

Named party
Undisclosed
Status
Undisclosed
Source position
Subcontracting is permitted, but the award and cited project records do not name downstream companies or allocate packages.
OPS boundary

Vessel electrical supply and berth connection

Named party
Separate APBA programme; no contractor evidenced under expediente 2026-037
Status
Not evidenced
Source position
The award package serves concession-user utility distribution and contains no vessel outlet, cable-management, frequency-conversion, ship-interface or OPS commissioning scope. Source
Contract and delivery

Formalization, setting-out, execution, energisation and reception

Named party
APBA and VES Renewable
Status
Not evidenced
Source position
The award defines future formalization and delivery terms; no signed contract, execution-clock start, progress or acceptance record is public.

Project timeline

Material developments

Dated events that changed scope, counterparties, delivery, commissioning or operating status.

Open this project in the Change Log

VES Renewable awarded the electrical works

APBA selected VES Renewable at EUR 273,030.32 excluding VAT after four tenders, while formalization and setting-out remain unconfirmed.

Source

Simplified open works procedure published

Publication opened the four-month works package against a EUR 274,402.34 excluding-VAT baseline, before the authority named a selected contractor.

Source

Execution project reached final approval signature

The approved Gabitel package fixed the 20 kV, 357.07 kW, 400 kVA and user-distribution design baseline for procurement and delivery.

Source

Distribution access and connection permission recorded

E-Distribucion's embedded conditions confirmed 357.07 kW of access at 20 kV, establishing the utility basis later carried into the execution project.

Source

Evidence gap

What remains unverified

Outstanding evidence

  • Contract formalization and setting-out verification act
  • Municipal licence, site possession and four-month baseline
  • Civil trenching and electrical lower-tier appointments
  • Transformer, MV cells, LV board, cable and enclosure manufacturers
  • E-Distribucion material approvals, testing and network transfer
  • Energisation and migration of fishing-wharf concession users
  • Reception, certifications, variations and final value
  • Separate APBA awards for Tarifa vessel supply points or OPS

Related records 2

Reporting status

Award, confirmed confidence

Last checked 9 August 2026 across 5 cited sources. The dated timeline above carries the project events.

Last checked 9 August 2026 Cited sources 5
